January 2007
2-322
WorkCentre 7132
024-747
Revision
Status-indicator-raps
024-747 Print Instruction RAP
Error in the combination of print parameters (stored file size, paper size, source paper tray,
duplexing, output destination).
Procedure
The center tray will not receive output, and output goes to Finisher (if Finisher is avail-
able).
YN
Go to Service Call Procedures.
Key operator is available to change settings.
YN
NOTE: Service procedure to restore output capability to center tray on Top Cover (PL
10.1).
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (Entering UI Diagnostics).
b. Access Diagnostic Routines (Accessing Diagnostic routines).
2. Select NVM Read/Write.
3. Enter Chain-Link 742-261
4. Select Confirm.
NOTE: Display now shows Current Value (Zero)
5. To enter new value (one), press 1 on the numeric keypad, then Select Save
NOTE: The Current Value now reads 1.
6. Select Close.
7. Select Close again. Power off and on if the setting is not active.
NOTE: Customer procedure to restore output capability to center tray on Top Cover (PL 10.1)
1. Press the Log In / Out Button on the Control Panel and enter (five one’s) 11111 using the
number keypad and select Confirm.
2. Select System Settings.
3. Select System Settings again.
4. Select Common Settings.
5. Select Other Settings.
6. Select Change Setting.
7. Select Offset Stacking Module.
8. Select Save.
9. Select Close.
10. Select Close again.
11. Select Close again.
12. Select Exit. Power off and on if the setting is not active.
