Xerox WorkCentre 7132 Service Documentation

January 2007
2-83
WorkCentre 7132
005-194
Status-indicator-raps
Revision
005-194 Mixed Size Mismatch RAP
BSD-ON:5.1
In Mixed Size Originals, it was detected that the Fast Scan Direction size was different from the
width of the document guide.
Initial Actions
Power Off than On
Check the document guide and repeat the operation.
Check the operation of the Tray Side Guide (Front).
Check the operation of the Tray Side Guide (Rear).
Procedure
Execute Component Control [005-221]. Actuate the DADF Tray Size 1 Sensor with paper. The
display changes.
YN
Check the connections of P/J771 and P/J759. P/J771 and P/J759 are connected cor-
rectly.
YN
Connect P/J771 and P/J759.
Check the wire between J771 and J759 for an open circuit or a short circuit (BSD 5.1Flag
1/Flag 2).
The wire between J771 and J759 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P759-3 (+) and GND (-) (BSD 5.1 Flag 2).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P759-2 (+) and GND (-) (BSD 5.1 Flag
1).Actuate the DADF Tray Size 1 Sensor with paper.
The voltage changes.
YN
Replace the DADF Tray Size 1 Sensor (PL 16.10).
Replace the DADF PWB (PL 16.3).
Execute Component Control [005-222]. Actuate the DADF Tray Size 2 Sensor with paper. The
display changes.
YN
Check the connections of P/J772 and P/J759. P/J772 and P/J759 are connected cor-
rectly.
YN
Connect P/J772 and P/J759.
Check the wire between J772 and J759 for an open circuit or a short circuit (BSD 5.1 Flag
3/Flag 4).
The wire between J772 and J759 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P759-6 (+) and GND (-) (BSD 5.1 Flag 4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P759-5 (+) and GND (-) (BSD 5.1 Flag
3).Actuate the DADF Tray Size 2 Sensor with paper.
The voltage changes.
YN
Replace the DADF Tray Size 2 Sensor (PL 16.10).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
A
A
B
B
