January 2007
2-841
WorkCentre 7132
124-333, 124-334
Status-indicator-raps
Revision
124-333 ASIC RAP
BSD-ON:16.1
A decompression error occurred in an ESS ASIC (Application Specific Integrated Circuit).
Initial Actions
Power Off/On
Procedure
Pull out and insert the DIMM (PL 11.1) Switch on the power. The problem persists.
YN
Return to Service Call Procedures.
Check the connection of each ESS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 11.2)
If the problem persists replace the DDR DIMM (PL 11.2).
124-334 Standard Font ROM RAP
BSD-ON:16.1
An error was detected in the standard Built-In Font ROM.
Procedure
Replace the PS DIMM (PL 11.2)
