Xerox WorkCentre 7132 Service Documentation

January 2007
2-619
WorkCentre 7132
062-389, 062-392
Status-indicator-raps
Revision
062-389 Carriage Over Run RAP
BSD-ON: 3.1
The carriage scanned beyond safe limits.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures
Replace the IIT/IPS PWB (PL 13.3).
062-392 IIT/IPS PWB Memory Failure-1 RAP
BSD-ON: 3.1
• The IIT/IPS PWB RAM failed during the Read/Write operation.
• The Shading Memory failed during the Read/Write operation.
• The Gap Memory failed during the Read/Write operation.
• The ASIC (Application Specific Integrated Circuit) failed.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures
Replace the IIT/IPS PWB (PL 13.3).
