January 2007
2-595
WorkCentre 7132
045-310, 045-311
Status-indicator-raps
Revision
045-310 Image RAP
BSD-ON:6.2
The IIT image is not ready for transfer.
Procedure
Check the connectors and cables between the IIT/IPS PWB, CCD PWB, and the ESS PWB.
The connectors and cables are OK.
YN
Repair or replace as required (PL 13.3, PL 13.4, PL 11.2)
Power OFF and then ON. The problem continues.
YN
Rerun the job.
Replace the IIT/IPS PWB (PL 13.3).
045-311 Controller Communications RAP
BSD-ON:6.2
There is a Controller communications fault.
Procedure
Check the following PWBs for loose connections and/or defective cables:
• Printer PWB (PL 11.2)
• ESS PWB (PL 11.2).
• MCU PWB (PL 11.1).
Repair and/or replace as required.
To Next Page
