January 2007
2-873
WorkCentre 7132
134-210, 134-211
Status-indicator-raps
Revision
134-210 Fax Controller Parameter RAP
BSD-ON:17.1
The parameter value is incorrect or the required parameter is not sent.
Initial Actions
Power Off/On
Procedure
Pull out and insert the FCB PWB (PL 11.3). The problem persists.
YN
Return to Service Call Procedures.
Check the electrical connections on the FCB PWB (PL 11.3). The connectors are securely
connected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures.
Replace the FCB PWB (PL 11.3).
134-211 FCB PWB RAP
BSD-ON:17.1
A failure is detected on the FCB PWB.
Initial Actions
Power Off/On
Procedure
Check the electrical connections on the FCB PWB (PL 11.3).
If the problem persists replace the FCB PWB (PL 11.3).
To Next Page
