Xerox WorkCentre 7132 Service Documentation

January 2007
2-736
WorkCentre 7132
094-419, 094-420
Revision
Status-indicator-raps
094-419 2nd BTR Near End of Life RAP
The 2nd BTR is near end of life.
Procedure
Verify that the 2nd BTR is near end of life (Detailed Maintenance Activities). The 2nd BTR is
near end of life.
YN
Replace the MCU PWB (PL 11.1).
There is no need for service at this time. Return to Service Call Procedures.
094-420 IBT End of Life RAP
The IBT reached end of life.
Procedure
Verify that the IBT Belt Assembly is at end of life (Detailed Maintenance Activities). The IBT
Belt Assembly is at end of life.
YN
Replace the MCU PWB (PL 11.1).
Replace the IBT Belt Assembly (PL 6.2).

Xerox WorkCentre 7132 Specifications

General

Functions	Print, Copy, Scan, Fax
Printing Technology	Laser
Print Speed (Black)	32 ppm
Print Resolution	1200 x 1200 dpi
Max Resolution (BW)	1200 x 1200 dpi
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Copier Max Resolution	600 x 600 dpi
Connectivity	Ethernet, USB
Scanner Type	Flatbed
Fax Speed	33.6 Kbps
USB Connectivity	USB 2.0
Media Size	A4, Letter, Legal
Copy Speed (Black)	32 ppm
Display	Color Touch Screen
Network Connectivity	Ethernet
