073-102 Tray 3 Feed Out Sensor On Jam RAP
BSD-ON:8.3/8.4/8.5/8.6
The Tray 3 Feed Out Sensor did not actuate in the specified time.
Initial Actions
• If a grinding noise was reported or is heard with the 073-102 code, there may be incorrect
gear mesh between TTM Takeaway Clutch (PL 2.6) and it’s drive gear, located to the
right. Loosen the bracket fixing screws and reposition bracket for best gear mesh without
binding.
• Check that the paper path is free of foreign material and paper dust.
Procedure
Check the Transport Roll for wear and paper dust. The Transport Roll is ok.
YN
Replace the Transport Roll (PL 15.5).
Enter Component Control [073-103 Tray 3 Feed Out Sensor]. Actuate the Tray 3 Feed Out
Sensor (PL 14.3/PL 15.6) with paper.
The display changes.
YN
Check the connections of P/J825, P/J842 and P/J548. P/J825, P/J842 and P/J548
are connected correctly.
YN
Connect P/J825, P/J842 and P/J548.
Check the wires between P/J825 and P/J548 for an open circuit or a short circuit (BSD
8.5 Flag 4/Flag 5/Flag 6).
The wires between P/J825 and P/J548 is conducting with-
out an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P/J548-1 (+) and P/J548-2 (-) (BSD
8.5 Flag 5/Flag 6).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 14.7/PL 15.9).
Measure the voltage between the Tray Module PWB P/J548-3 (+) and GND (-) (BSD 8.5
Flag 4. Actuate the Tray 3 Feed Out Sensor (PL 14.3/PL 15.6) with paper.
The voltage
changes.
YN
Replace the Tray 3 Feed Out Sensor (PL 14.3/PL 15.6).
Replace the Tray Module PWB (PL 14.7/PL 15.9).
Enter Component Control [077-022 2TM/TTM Takeaway Motor ON]. The 2TM/TTM Takeaway
Motor (PL 14.7/PL 15.9) can be heard.
YN
Check the connections of P/J826 and P/J552. P/J826 and P/J552 are connected cor-
rectly.
YN
Connect P/J826 and P/J552.
Check the wires between P/J826 and P/J552 for an open circuit or a short circuit (BSD
8.4 Flag 1 / BSD 8.6 Flag 1).
The wires between J826 and J552 is conducting without
an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Tray Module PWB (PL 14.7/PL 15.9).
Check the paper transport drives and repair as required (PL 14.7/PL 15.9).
A
A
