January 2007
2-604
WorkCentre 7132
045-337
Revision
Status-indicator-raps
045-337 Marking Imaging Communication RAP
BSD-ON:6.4/6.5
There is a marking/imaging communication error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
