042-311 Auger Motor Failure RAP
BSD-ON:4.1B
The Auger Motor is not rotating at the specified speed.
Initial Actions
• Power OFF/ON
Procedure
Close the LH Cover and the Front Cover.
Execute Component Control [042-003 Auger Motor ON]. The Auger Motor can be heard.
YN
Go to the BSD 4.2B and troubleshoot the circuit.
Check the installation of the Drum Drive Assembly (PL 1.1). The Drum Drive Assembly is
installed correctly.
YN
Install the Drum Drive Assembly correctly.
Check the wire between J410 and J215 for an open circuit or a short circuit (BSD 4.2B). The
wires are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Manually rotate the Auger Motor rotor. It rotates smoothly.
YN
Check for foreign substances that are interfering with operation or installation failure.
Foreign substances or installation failure are found.
YN
Replace the Drum Drive Assembly (PL 1.1).
Remove the foreign substances that are interfering with operation and correct the installa-
tion failure.
Replace the Drum Drive Assembly (PL 1.1) If the problem persists, replace the MCU PWB (PL
11.1).
042-313 Rear Cooling Fan Failure RAP
BSD-ON:13.1
The Rear Cooling Fan Failed.
Procedure
Execute Component Control [042-006 Rear Fan ON]. The Rear Fan rotates.
YN
Check connectors J 409 on the MCU PWB and J 224 on the Rear Fan (PL 11.1). The
connector or connected.
YN
Connect connector.
Check the wires between J 409 on the MCU PWB and J 224 on the Rear Fan for an open
or shot circuit.
The wires are OK.
YN
Repair or replace as needed.
Check J 409-15A (+) and J 409-18A (-) for +24VDC +24VDC is present.
YN
Troubleshoot the +24VDC circuit (BSD 1.2).
Replace the Rear Fan (PL 11.1).
Check for obstructions in the area of the Rear Fan (PL 11.1).
