WorkCentre 7132
077-907 , 077-967
Revision
Status-indicator-raps
077-907 Duplex Wait Sensor RAP
BSD-ON:10.6
Paper remains on the Duplex Sensor.
Procedure
Execute Component Control [077-104 Duplex Sensor]. Actuate the Duplex Sensor (PL 10.1)
with paper.
The display changes to L.
YN
Check the wire between J123 and J541 for an open circuit or a short circuit (BSD 10.6
Flag 1/Flag 2).
The wire between J123 and J541 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Duplex Sensor (PL 10.1) If the problem persists, replace the Duplex PWB
(PL 10.1).
Replace the Duplex PWB (PL 10.1).
077-967 Paper Kind Mismatch RAP
The specified paper type and the paper type being used are different.
Initial Actions
Perform the following:
• Switch the power off then on.
• Check if the Regi Sensor actuator is operating properly.
• Check the paper type.
• Check the paper type settings.
Procedure
Load the paper type selected. If problem still exists, replace the MCU PWB (PL 11.1).
