January 2007
2-163
WorkCentre 7132
012-600, 012-901
Status-indicator-raps
Revision
012-600 Staple Mode Logic
Stapling cannot be selected for the size of paper in the tray.
Procedure
Job can be reprogrammed with different staple setting or paper size.
YN
Redesign Job.
Reprogram job.
012-901 Finisher H-Transport Entrance Sensor RAP
BSD-ON:12.2
Paper remains on the H-Transport Entrance Sensor.
Initial Actions
• Remove foreign substances on the sensor.
• Power Off/On
Procedure
Execute Component Control [012-190 H-Transport Entrance Sensor]. Actuate the H-Transport
Entrance Sensor with paper.
The display changes.
YN
Check the connections of P/J8380 and P/J8390. P/J8380 and P/J8390 are con-
nected correctly.
YN
Connect P/J8380 and P/J8390.
Check the wire between J8380 and J8390 for an open circuit or a short circuit (BSD 12.2
Flag 5/Flag 6).
The wire between J8380 and J8390 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8390-12 (+) and GND (-) (BSD 12.2
Flag 6).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Measure the voltage between the Finisher PWB P8390-13 (+) and GND (-) (BSD 12.2
Flag 5).
Actuate the H-Transport Entrance Sensor with paper. The voltage changes.
YN
Replace the H-Transport Entrance Sensor (PL 17.3).
Replace the Finisher PWB (PL 17.12).
Replace the Finisher PWB (PL 17.12).
To Next Page
