Xerox WorkCentre 7132 Service Documentation

January 2007
6-9
WorkCentre 7132
IOT NVM List
General procedures information
Reversion 4.0
IOT NVM List Chain 740-xxx IOT Manager
Table 1 Chain 740-xxx IOT Manager
Chain-Link Name Default Range Read/Write Description
740-003 CycleDownTimer for SheetEmpty 0 0~5000 RW Cycle Down Timer (in steps of 1ms) for the state in which Tray is empty. Timer measuring
time from the time Tray becomes empty during printing to the start of Cycle Down.
When having a failure or instructed to stop, the M/C immediately starts to cycle down
without using this Timer.
740-004 IOT-PL Number 0 0~255 R IOT-PL management number written in ROM built in CPU.
At Power On, IOT-PL info is checked and stored in this NVM.
0-255: IOT-PL management number available
740-006 Comm Fail History ID 1 0~255 RW Where to connect in the event of a fail:
0x00: Controller
0x01: No occurrence
740-007 Comm Fail History State 0 0~255 RW Communication Fail Type
1: Send Queue NG
2: No ACK
3: Receive Queue Full
740-008 Comm Fail History Tx State 0 0~255 RW Transmission status in the event of a fail:
0: Idling (waiting)
1: Sending Msg
2: Waiting for Ack to sent Msg
3: Waiting for Ack to sent Sync
4: Checking Send Queue after sending Msg
740-009 Comm Fail History Rx State 0 0~255 RW Reception status in the event of a fail:
0: Idling (waiting)
1: Waiting for Msg Length
2: Waiting for ClientData/BCC
3: Waiting to receive Command to Establish Sync.
4: Finished receiving Msg
5: Finished receiving Command to Establish Sync.
740-010 Comm Fail History Uart Tx Use 0 0~255 RW For what Physical Layer is used in the event of a fail:
0: Send physical layer used to send Msg
1: Send physical layer used to send Ack
740-011 Comm Fail History Rx Func Use 0 0~255 RW How the M/C waits for a Receive Function in the event of a fail:
0: Clear the use of Receive Function
1: Set the use of Receive Function
740-012 FPGA Video Version 0 0~255 R Version of FPGA Video Module
740-013 FPGA I/O Version 0 0~255 R Version of FPGA I/O Module
740-014 Logic Fail Information 0 0~255 RW Type 0-99: IM
Type 100-: Library/DD-Num
740-015 Logic Fail Information 0 0~255 RW Detail 1
740-016 Logic Fail Information 0 0~255 RW Detail 2
740-017 Logic Fail Information 0 0~255 RW Detail 3
