Xerox WorkCentre 7132 Service Documentation

January 2007
6-7
WorkCentre 7132
NVM Read/Write
General procedures information
Reversion 4.0
NVM Read/Write
Purpose
Reads, sets or changes the NVM data.
Procedure
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (Entering UI Diagnostics in UI Diagnostic Mode).
b. Access Diagnostic Routines (Accessing Diagnostic Routines in UI Diagnostic
Mode).
2. Select Maintenance/Diagnostics.
3. Select NVM Read/Write.
Reading NVM
1. Input Chain-Link number(6 digits) on NVM Read/Write screen.
2. Select Confirm/Change.
3. Current Value appears in Current Value column.
Writing NVM
1. Input New number in New Value column.
2. Select Save.
3. New number appears on Current Value column.
Table 1 Component VS Chain number
Component Item IOT/IIT/Controller Chain Number Allocation
ESS IF IOT 740
Recycle IOT 740
Billing IOT 740
Drive IOT 741
NOHAD IOT 741
PH IOT 740, 742, 760
EXIT IOT 742, 764
Tray IOT 742
Fuser IOT 744
ROS IOT 749
Process Control IOT 751, 752, 753
Xero IOT 751
CRU IOT 751
Finisher IOT 764
DADF IIT 711
IISS (DADF) IIT 710
IISS IIT 715
IISS (Config) IIT 719
Common Controller 700
Meter Counter Controller 720
Stored Data Controller 731, 732, 733, 734
I/O Port Protocol Controller 770
Scan Service Controller 770, 840
IOT Controller 780
IIT Controller 785
UI Controller 790
Copy Service Controller 790, 810
Print Service Controller 800, 806
Fax Service Controller 820, 823, 825
iFax Service Controller 830
Diagnostics Controller 870, 900
Table 1 Component VS Chain number
Component Item IOT/IIT/Controller Chain Number Allocation
