January 2007
2-688
WorkCentre 7132
077-902
Revision
Status-indicator-raps
077-902 Exit Sensor 2 On Jam RAP
BSD-ON:10.3
Paper remains on the Exit 2 Sensor.
Procedure
Execute Component Control [077-102 Exit 2 Sensor]. Actuate the Exit 2 Sensor (PL 8.4) with
paper.
The display changes to L.
YN
Check the wire between J112 and J434 for an open circuit or a short circuit (BSD 10.3
Flag 1/Flag 2).
The wire between J112 and J434 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Exit 2 Sensor (PL 8.4) (PL 9.1).
Replace the Exit PWB (PL 9.1).
To Next Page
