January 2007
2-713
WorkCentre 7132
092-651, 092-661
Status-indicator-raps
Revision
092-651 ADC Shutter Clean RAP
BSD-ON:9.4A
There is an ADC Sensor Voltage level failure.
Procedure
Remove the Sensor Bar Assembly (PL 11.1). Check the condition of the Sensor Bar Assem-
bly. The ADC Assembly is free of damage.
YN
Replace the Sensor Bar Assembly (PL 11.1).
Check the operating voltages between the ADC Sensor and the MCU PWB. The voltages are
correct.
YN
Replace the MCU PWB (PL 11.1).
Replace the Sensor Bar Assembly (PL 11.1).
092-661 Temperature Sensor RAP
BSD-ON:9.4A
There is a temperature sensor failure.
Procedure
Check the operating voltages between the Temperature/Humidity Sensor and the MCU PWB.
The voltages are correct.
YN
Verify that the circuit is not damaged. If no damage is found, replace the MCU PWB (PL
11.1).
Replace the Temperature/Humidity Sensor (PL 11.1).
