Xerox WorkCentre 7132 Service Documentation

January 2007
2-871
WorkCentre 7132
133-280, 133-281
Status-indicator-raps
Revision
133-280 Fax Option Slot 1 Board RAP
BSD-ON:17.1
Failure was detected on the Fax Option Slot 1 board.
Procedure
Pull out and insert the FCB PWB (PL 11.3) Switch on the power. The problem persists.
YN
Service Call Procedures.
Check the connection of each FCB PWB (PL 11.3) connector. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Service Call Procedures.
Replace the FCB PWB (PL 11.3).
133-281 Received unknown message RAP
BSD-ON:17.1
A message not specified in I/F settings was received from the Fax Card.
Procedure
Pull out and insert the FCB PWB (PL 11.3) Switch on the power. The problem persists.
YN
Service Call Procedures.
Check the connection of each FCB PWB (PL 11.3) connector. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Service Call Procedures.
Replace the FCB PWB (PL 11.3).
