January 2007
2-725
WorkCentre 7132
093-916, 093-924
Status-indicator-raps
Revision
093-916 Toner K CRUM not in position Failure
BSD-ON:9.1
K Toner CRUM not in position Failure.
Initial Actions
• Ensure that the Black Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-970 (Y), 093-971 (M), and 093-972 (C) are also present on the UI.
YN
Replace the Black Toner Cartridge (PL 5.2).
Replace the Toner CRUM (Toner Cartridge Door) (PL 5.1).
If the fault codes are still present, replace the MCU PWB (PL 11.1).
093-924 Toner K Crum Communication Failure
BSD-ON:9.1
K Toner CRUM Comm Failure.
Initial Actions
• Ensure that the Black Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-940 (Y), 093-941 (M), and 093-942 (C) are also present on the UI.
YN
Replace the Black Toner Cartridge (PL 5.2).
Replace the Toner CRUM (Toner Cartridge Door) (PL 5.1).
If the fault codes are still present, replace the MCU PWB (PL 11.1).
To Next Page
