January 2007
2-96
WorkCentre 7132
005-302, 005-304
Revision
Status-indicator-raps
005-302 CVT Feeder Cover Interlock Open RAP
BSD-ON:1.3
The DADF Interlock is open.
Initial Actions
• Power Off than On
Procedure
Check opening/closing of the Feeder Cover. The Feeder Cover can be opened/closed.
YN
Reinstall the Feeder Cover correctly.
Check installation of the DADF Interlock Switch. The DADF Interlock Switch is installed cor-
rectly.
YN
Install the DADF Interlock Switch correctly.
Execute Component Control [005-212 DADF Interlock Switch]. Open and close the Feeder
Cover.
The display changes.
YN
Check the connections of P/J753, F1 and F2. P/J753, F1 and F2 are connected cor-
rectly.
YN
Connect P/J753, F1 and F2.
Check the wire between J753 and F1, and between J753 and F2 for an open circuit or a
short circuit (BSD 1.3 Flag 7/Flag 8).
The wires between J753 and F1, and between
J753 and F2 are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the DADF Interlock Switch between J753-2 and J753-1 (BSD
1.3 Flag 7/Flag 8).
The wire between J753-2 and J753-1 is connecting successfully
when the DADF Interlock Switch contact is closed, and is insulated when the con
-
tact is opened.
YN
Replace the DADF Interlock Switch (PL 16.7).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
005-304 CVT Platen Interlock Open RAP
BSD-ON:6.1
The Platen Interlock is open.
Initial Actions
• Power Off than On
Procedure
Check opening/closing of the Platen Cover. The Platen Cover can be opened/closed.
YN
Reinstall the Platen Cover correctly.
Check the installation of the Platen Open Switch. The Platen Open Switch is installed cor-
rectly.
YN
Install the Platen Open Switch correctly.
Execute Component Control [062-300 Platen Open Switch]. Open and close the Platen
Cover. The display changes.
YN
Check the connections of P/J727 and P/J722. P/J727 and P/J722 are connected cor-
rectly.
YN
Check the wire between J727 and J722 for an open circuit or a short circuit (BSD 6.1
Flag 3/Flag 4). The wire between J727 and J722 is conducting without an open cir
-
cuit or a short circuit.
Connect P/J727 and P/J722.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Platen Open Switch between J722A-10 and J722A-11 (BSD
6.1 Flag 3/Flag 4).
The wire between J722A-10 and J722A-11 is connecting success-
fully when the Platen Open Switch contact is closed, and is insulated when the con-
tact is opened.
YN
Replace the Platen Open Switch (PL 13.4).
Replace the IIT/IPS PWB (PL 13.3).
Replace the IIT/IPS PWB (PL 13.3).
