January 2007
4-23
WorkCentre 7132
REP 4.1.1
Repairs/Adjustments
Reversion 4.0
REP 4.1.1 Developer Housing
Parts List on PL 5.1
Removal
WARNING
To avoid personal injury or shock, do not perform repair or adjustment with electrical
power applied to the machine.
1. Ensure that the “Ready to Copy” is displayed on the Control Panel display.
2. Switch off the power and disconnect the Power Cable.
3. Remove the Toner Cartridge of the Developer Housing to be removed.
4. Remove the Front Cover. (REP 10.2.2)
5. Remove the Low Voltage Power Supply. (REP 9.2.3)
6. Prepare to remove the Rotary Cover. (Figure 1)
Figure 1 Preparing to remove the Rotary Cover
7. Remove the Rotary Cover. (Figure 2)
Figure 2 Removing the Rotary Cover
8. Open the Toner/Developer Access Door.
9. Prepare to remove the Developer Housing. (Figure 3)
1. Push in and hold the Rotary Release Knob.
2. Manually rotate the Rotary until the Developer Housing to be removed is in position
then release the rotary Release Knob.
3. Remove the screw (1).
Remove the screws (2)
Rotary Cover
To Next Page
