January 2007
2-603
WorkCentre 7132
045-335, 045-336
Status-indicator-raps
Revision
045-335 Marking Fuser Communication RAP
BSD-ON:
There is a marking/fuser communication error.
Procedure
Check the connections and wiring between the MCU PWB and the Fuser. The connections
and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the Fuser (PL 5.1). If the problem continues, replace the MCU PWB (PL 11.1).
045-336 Marking ROS Communication RAP
BSD-ON:6.4/6.5
There is a marking/ROS communication ROS error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
