January 2007
2-332
WorkCentre 7132
024-934, 024-946
Revision
Status-indicator-raps
024-934 Paper Type Mismatch RAP
BSD-ON:
There is no description available at time of publication.
Procedure
There is no procedure available at time of publication.
024-946 Tray 1 Position RAP
BSD-ON:7.1
The Tray 1 Paper Size Switch detected no tray.
Initial Actions
• Reload the tray correctly.
• Check the operation of the tray actuator.
Procedure
(TM)
Remove Trays 1 and 2. Replace Tray 1 with Tray 2. [024-946] occurs.
YN
Replace the faulty part of the Tray 1 Actuator.
Check the installation of the Tray 1 Paper Size Switch. The Tray 1 Paper Size Switch is
installed correctly.
YN
Install the Tray 1 Paper Size Switch correctly.
Go to the OF 2 (SIZE SWITCH ASSY RAP).
To Next Page
