072-102 Tray 2 Feed Out Sensor On Jam (Tray 3 Feed) RAP
BSD-ON:8.3/8.4
The Tray 2 Feed Out Sensor did not actuate in time after the Tray 3 Feed Out Sensor actuated.
Initial Actions
Check that the paper path is free of foreign material and paper dust.
Procedure
Enter Component Control [072-103 Tray 2 Feed Out Sensor]. Actuate the Tray 2 Feed Out
Sensor (PL 14.3/PL 15.6) with paper.
The display changes.
YN
Check the connections of P/J821, P/J841 and P/J548. P/J821, P/J841 and P/J548
are connected correctly.
YN
Connect P/J821, P/J841 and P/J548.
Check the wires between P/J821 and P/J548 for an open circuit or a short circuit (BSD
8.3 Flag 1/Flag 2/Flag 3).
The wires between P/J821 and P/J548 is conducting with-
out an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P/J548-8 (+) and P/J548-9 (-) (BSD
8.3 Flag 2/Flag 3).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 14.7/PL 15.9).
Measure the voltage between the Tray Module PWB P/J548-10 (+) and GND (-) (BSD
8.2 Flag 1). Actuate the Tray 2 Feed Out Sensor (PL 14.3/PL 15.6) with paper.
The volt-
age changes.
YN
Replace the Tray 2 Feed Out Sensor (PL 14.3/PL 15.6).
Replace the Tray Module PWB (PL 14.7/PL 15.9).
Enter Component Control [077-022 2TM/TTM Takeaway Motor ON]. The 2TM/TTM Takeaway
Motor (PL 14.7/PL 15.9) can be heard.
YN
Check the connections of P/J826 and P/J552. P/J826 and P/J552 are connected cor-
rectly.
YN
Connect P/J826 and P/J552.
Check the wires between P/J826 and P/J552 for an open circuit or a short circuit (BSD
8.4 Flag 1 / BSD 8.6 Flag 1).
The wires between J826 and J552 is conducting without
an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Tray Module PWB (PL 14.7/PL 15.9).
Check the paper transport drives and repair as required (PL 14.5, PL 14.7/PL 15.8, PL 15.9).
