089-632 IBT Belt Cleaner RAP
BSD-ON:9.8/9.9
IBT Belt Cleaner Impact Failure.
Procedure
Remove the IBT Cleaner Assembly and check the cleaner blade and auger area for impacted
toner.
The IBT Belt Cleaner is free of toner.
YN
Clean the IBT Belt Cleaner Assembly. If the problem continues, replace the IBT Belt
Cleaner (PL 6.1).
Check the Toner Waste area for impacted toner. The Waste Toner area is free of tone.
YN
Replace the Waste Toner Bottle (PL 4.1).
Check the Front Auger for impacted toner. Clean or replace as required (PL 6.1).
089-633 2nd BTR RAP
BSD-ON:9.7
The 2nd BTR impacted Failure
Procedure
Check the 2nd BTR, Backup Roll, and the Detact Saw for impacted toner. The 2nt BTR area
is free of toner.
YN
Clean and/or replace the 2nd BTR Assembly (PL 2.7).
Check the 2nd BTR area for contamination, binding or wear. Repair or replace the 2nd BTR
Assembly (PL 2.7).
