January 2007
3-34
WorkCentre 7132
103mm Streaks from the lead edge Defect
Reversion 4.0
Image Quality
103mm Streaks from the lead edge Defect
Figure 1 103mm Streaks Defect Sample (VA-008)
Cause
The 103mm streaks appear in the same position of the black images, 201 mm from the lead
edge.
Corrective Action
Replace the 2nd BTR (PL 2.7).
