Xerox WorkCentre 7132 Service Documentation

January 2007
2-291
WorkCentre 7132
018-785, 018-786
Status-indicator-raps
Revision
018-785 LDAP RAP
There is an error in the Lightweight Directory Access Protocol.
Procedure
Verify that print jobs are printing or print a Configuration Report and verify that network setup
settings are indicated.
The printer is operational or the Config Report indicates valid net-
work settings.
YN
Check for damage with the network connection. If there is no damage then there is a
problem with the network. Tell the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server. Ask
the customer to verify the machine LDAP setups. If OK then there is a problem with the remote
LDAP server.
018-786 LDAP RAP
There is an error in the Lightweight Directory Access Protocol.
Procedure
Verify that print jobs are printing or print a Configuration Report and verify that network setup
settings are indicated.
The printer is operational or the Config Report indicates valid net-
work settings.
YN
Check for damage with the network connection. If there is no damage then there is a
problem with the network. Tell the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server. Ask
the customer to verify the machine LDAP setups. If OK then there is a problem with the remote
LDAP server.
