Xerox WorkCentre 7132 Service Documentation

January 2007
2-88
WorkCentre 7132
005-199, 005-210
Revision
Status-indicator-raps
Execute Component Control[005-206]. Actuate the DADF Pre Registration Sensor with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-12 (+) and GND (-) (BSD 5.4 Flag
4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P761-11 (+) and GND (-) (BSD 5.4 Flag 3).
Actuate the DADF Pre Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Pre Registration Sensor (PL 16.7).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
005-210 DADF Download Fail
DADF Download mode detected at IISS start (Power On, Energy Save recovery included).
DADF Download failed. ROM is broken.
Power ON after replacement of ROM by half-burnt ROM in field.
Procedure
Replace the DADF PWB (PL 16.3).
