January 2007
2-151
WorkCentre 7132
012-302, 012-303
Status-indicator-raps
Revision
012-302 Finisher Front Cover Open RAP
BSD-ON:12.1
The Finisher Front Cover is open.
Initial Actions
• Power Off/On
• Opening/closing of the Finisher Front Cover.
Procedure
Check opening/closing of the Finisher Front Cover. The Finisher Front Cover can be
opened/closed.
YN
Reinstall the Finisher Front Cover correctly.
Check the installation of the Front Door Interlock Switch. The Front Door Interlock Switch is
installed correctly.
YN
Install the Front Door Interlock Switch correctly.
Execute Component Control [012-302 Front Door Interlock Switch]. Open/close the Finisher
Front Cover. The display changes.
YN
Check the connections of P/J8809 and P/J8851. P/J8809 and P/J8851 are con-
nected correctly.
YN
Connect P/J8809 and P/J8851.
Check the wire between J8809 and J8851 for an open circuit or a short circuit (BSD 12.1
Flag 1/Flag 2).
The wire between J8809 and J8851 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Front Door Interlock Switch between J8809-3 and J8809-4
(BSD 12.1 Flag 1/Flag 2).
The wire between J8809-3 and J8809-4 is connecting suc-
cessfully when the Front Door Interlock Switch contact is closed, and is insulated
when the contact is opened.
YN
Replace the Front Door Interlock Switch (PL 17.12).
Replace the Finisher PWB (PL 17.12).
Replace the Finisher PWB (PL 17.12). If the problem persists, replace the MCU PWB (PL
11.1).
012-303 Finisher H-Transport Cover Open RAP
BSD-ON:12.2
The Finisher H-Transport Cover is open.
Initial Actions
• Power Off/On
• Opening/closing of the Finisher H-Transport Cover.
Procedure
Check opening/closing of the Finisher H-Transport Cover. The Finisher H-Transport Cover
can be opened/closed.
YN
Reinstall the Finisher H-Transport Cover correctly.
Check the installation of the H-Transport Interlock Sensor. The H-Transport Interlock Sensor
is installed correctly.
YN
Install the H-Transport Interlock Sensor correctly.
Execute Component Control [012-303 H-Transport Interlock Sensor]. Open and close the Fin-
isher H-Transport Cover. The display changes.
YN
Check the connections of P/J8382 and P/J8390. P/J8382 and P/J8390 are con-
nected correctly.
YN
Connect P/J8382 and P/J8390.
Check the wire between J8382 and J8390 for an open circuit or a short circuit (BSD 12.2
Flag 1/Flag 2).
The wire between J8382 and J8390 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8390-7 (+) and GND (-) (BSD 12.2 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the H-Transport Interlock Sensor (PL 17.12).
Measure the voltage between the Finisher PWB P8390-8 (+) and GND (-) (BSD 12.2 Flag
1). Open and close the Finisher H-Transport Cover.
The voltage changes.
YN
Replace the H-Transport Interlock Sensor (PL 17.3).
Replace the Finisher PWB (PL 17.12).
Replace the Finisher PWB (PL 17.12). If the problem persists, replace the MCU PWB (PL
11.1).
