January 2007
2-597
WorkCentre 7132
045-323, 045-324
Status-indicator-raps
Revision
045-323 Marking Y RAP
BSD-ON:6.4/6.5
There is a marking Y plate control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
045-324 Marking M RAP
BSD-ON:6.4/6.5
There is a marking M plate control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
