January 2007
2-596
WorkCentre 7132
045-321, 045-322
Revision
Status-indicator-raps
045-321 Marking Panel RAP
BSD-ON:6.2
There is an internal marking panel control error.
Procedure
Check the connectors and cables between the IIT/IPS PWB, CCD PWB, and the ESS PWB.
The connectors and cables are OK.
YN
Repair or replace as required (PL 13.3, PL 13.4, PL 11.2)
Power OFF and then ON. The problem continues.
YN
Rerun the job.
Replace the IIT/IPS PWB (PL 13.3). If the problem continues, replace the ROS (PL 3.1).
045-322 Marking Pitch RAP
BSD-ON:6.4/6.5
There is an internal marking pitch control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the ROS Unit (PL 3.1). If the problem continues, replace the MCU PWB (PL 11.1).
