January 2007
2-90
WorkCentre 7132
005-280, 005-281
Revision
Status-indicator-raps
005-280 DADF EEPROM RAP
BSD-ON:3.5
The DADF-EEPROM failed during the Read/Write operation.
Initial Actions
• Power Off than On
Procedure
Check the connection of each DADF PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Turn on the power again. [005-280] reoccurs.
YN
End
Replace the DADF PWB (PL 16.3).
005-281 DADF Tray Lift Down Failure
Bottom Sensor does not turn ON in specified time from start of DADF Tray Down.
Procedure
To check Bottom Sensor output/Tray Motor operation/Tray Drive system (Torque Limiter)/Sen-
sor Actuator. Check the connections between the sensor and the DADF PWB. If OK, replace
the Bottom Sensor. If the problem persists, replace the DADF PWB (PL 16.3).
To Next Page
