Xerox WorkCentre 7132 Service Documentation

January 2007
2-844
WorkCentre 7132
124-340, 124-341
Revision
Status-indicator-raps
124-340 CRUM Market RAP
BSD-ON:16.1
There is a general CRUM control failure.
Procedure
Check the electrical connections on the ESS PWB and MCU PWB. The connectors are
securely connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 11.2)
If the problem persists replace the MCU PWB (PL 11.1).
124-341 CRUM Market MCU RAP
CRUM control failed on the MCU.
Procedure
Check the electrical connections on the ESS PWB and MCU PWB. The connectors are
securely connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Perform GP 4, repair the problem by master SYS1.
If the problem persists, replace the MCU PWB (PL 11.1).
