Page #742 background image
January 2007
2-709
WorkCentre 7132
091-915, 091-916
Status-indicator-raps
Revision
091-915 Xero CRUM Data RAP
BSD-ON:9.1
The Control Logic detected incorrect data on the Xero CRUM.
Initial Actions
Check NVM location 740-047, for Geographic area:
• NA/EU = 3
• DMO-E/W = 12
• All the World = 512
Check NVM location 740-049, for Contact Type:
• Metered = 3
• Sold = 2
• Neutral = 31
Procedure
Pull out and reinstall the Xerographics Drum Module. The problem persists.
YN
Return to Service Call Procedures.
An incorrect Xerographics Drum Module was just installed. Install the correct Xerographics
Drum Module.
091-916 Xero CRUM Match RAP
BSD-ON:9.1
The Control Logic detected mismatched data on the Xero CRUM.
Initial Actions
Check NVM location 740-047, for Geographic area:
•NA/EU = 3
• DMO-E/W = 12
• All the World = 512
Check NVM location 740-049, for Contact Type:
• Metered = 3
•Sold = 2
• Neutral = 31
Procedure
Pull out and reinstall the Xerographics Drum Module. The problem persists.
YN
Return to Service Call Procedures.
An incorrect Xerographics Drum Module was installed. Verify the position of the Xerographics
Drum Module. Install the correct Xerographics Drum Module.
