January 2007
2-71
WorkCentre 7132
005-138, 005-139
Status-indicator-raps
Revision
005-138 CVT Exit 1 Sensor On Jam (Side 2)
BSD-ON:5.4
Exit 1 Sensor does not turn On in specified time from Exit 2 Sensor On in Reverse Output
operation.
Procedure
If the problem occurs frequently, check the following:
1. There is any area in document path that interferes with document feed.
2. Any foreign substance is attached to Roll surface.
3. Roll surface has worn abnormally.
4. Exit Gate is in normal position (Exit Gate Solenoid operation included.)
5. Feed Motor rotates normally.
6. Invert Roll performs normal Nip operation (Nip Release Solenoid operation included.)
7. Exit Motor rotates normally.
8. Exit Gate, closed, blocks path.
9. Check the connectors and wires for damage.
If all above are OK, replace Exit 1 Sensor (PL 16.7). If the problem continues, replace the Exit
2 Sensor (PL 16.7). If the problem persists, replace the DADF PWB (PL 16.3).
005-139 CVT Invert Sensor Off Jam RAP
BSD-ON:5.4/5.5/5.6
After the Registration Sensor turned Off during the Read operation, the Invert Sensor did not
turn Off within the specified time.
Initial Actions
• Power Off than On
Procedure
Check the installation and operation of the Invert Gate. The Invert Gate is installed and it
works.
YN
Install the Invert Gate correctly.
Execute Component Control [005-211]. Actuate the DADF Invert Sensor with paper. The dis-
play changes.
YN
Check the connections of P/J780 and P/J761. P/J780 and P/J761 are connected cor-
rectly.
YN
Connect P/J780 and P/J761.
Check the wire between J780 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
5/Flag 6).
The wire between J780 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-9 (+) and GND (-) (BSD 5.4 Flag 6).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P761-8 (+) and GND (-) (BSD 5.4 Flag 5).
Actuate the DADF Invert Sensor with paper. The voltage changes.
YN
Replace the DADF Invert Sensor (PL 16.7).
Replace the DADF PWB (PL 16.3).
Execute Component Control [005-026]. The DADF Registration Motor starts up.
YN
Check the connections of P/J765 and P/J755. P/J765 and P/J755 are connected cor-
rectly.
YN
Connect P/J765 and P/J755.
A B
