Xerox WorkCentre 7132

January 2007
6-75
WorkCentre 7132
IIT NVM List
General procedures information
Reversion 4.0
IIT NVM List
Chain 710-xxx DADF
Chain 711-xxx CVT DADF NVM LIST
Table 1 DADF
Chain-Link Content Default Range Meaning
710-501 Fax Document Size Detection Method for DADF 0 0~1 Indicates the switching of detection method when Fax Document Size Detection is specified in
DADF mode. 0: A/B series, 1: Inch series
710-551 JAM Bypass 0 0~1 0: Do not bypass, 1: Bypass Applies to CVT mode.
710-600 Size Mismatch Jam Detection Setting (Applicable
only in Simplex mode)
1 1~2 1: Size Mismatch Jam Detection On 2: Size Mismatch Jam Detection Off
710-603 Alternate Size Set3 0 0~2 PF1: Switches between 11x15S and 11x17S. No-Mix: mm, No-Mix/Size-Mix: Inch13/Inch14,0:
Default,1: 11x17S,2: 11x15S PF2: Switches between 11x15S and 11x17S. No-Mix: mm/Inch13/
Inch14, Size-Mix: Inch13/Inch14,0: Default,1: 11x17S,2: 11x15S
710-604 Alternate Size Set4 0 0~2 PF1: Switches between 8.46x12.4S, 8.5x13S and 8.5x14S. No-Mix/Size-Mix: mm,0: Default,1:
8.5x13S,2: 8.5x14S PF2: Switches between 8.5x13S and 8.5x14S. No-Mix/Size-Mix: mm Initial
value: 2,0: Default,1: 8.5x13S,2: 8.5x14S
710-605 Alternate Size Set5 0 0~2 PF1: Switches between BS5 and 16KS. No-Mix: mm,0: Default,1: B5S,2: 16KS PF2: Switches
between B5S and 16KS. No-Mix/Size-Mix: mm Initial value: mm,0: Default,1: B5S,2: 16KS
710-606 Alternate Size Set6 0 0~3 PF1: Switches between 8x10S, 8x10.5S and 8.5x11S. Size-Mix: Inch13/Inch14,0: Default,1:
8.5x11S,2: 8x10S,3: 8x10.5S PF2: Switches between 8x10S, 8x10.5S and 8.5x11S. Size-Mix:
Inch13/Inch14,0: Default,1: 8.5x11S,2: 8x10S,3: 8x10.5S
710-607 Alternate Size Set7 0 0~3 PF1: Switches between 8x10L, 8x10.5L and 8.5x11L. Size-Mix: Inch13/Inch14,0: Default,1:
8.5x11L,2: 8x10L,3: 8x10.5L PF2: Switches between 8x10L, 8x10.5L and 8.5x11L. Size-Mix: Inch13/
Inch14,0: Default,1: 8.5x11L,2: 8x10L,3: 8x10.5L
710-608 Alternate Size Set8 0 0~4 PF2: Switches between B4S, 8KS, 11x15S and 11x17S. Size-Mix: mm,0: Default,1: B4S,2: 8KS 3:
11x15S 4: 11x17S PF2: Switches between B4S, 8KS and 11x17S. Size-Mix: mm,0: Default,1:
B4S,2: 8KS 3: 11x17S PF2 setting range is 0~3.
710-609 Alternate Size Set9 0 0~2 PF1: Switches between 8x10S and 8x10.5S. No-Mix: Inch13/Inch14,0: Default,1: 8x10S,2: 8x10.5S
PF2: Switches between 8x10S and 8x10.5S. No-Mix: Inch13/Inch14,0: Default,1: 8x10S,2: 8x10.5S
710-610 Alternate Size Set10 0 0~2 PF1: Switches between B5L and 16KL. Size-Mix: mm,0: Default,1: B5L,2: 16KL PF2: Switches
between B5L, 16KL and 8.5x11L. Size-Mix: mm,0: Default 1: B5L,2: 16KL 3: 8.5x11L PF2 setting
range is 0~3.
710-612 Size-Mix Mode Size Orientation 1 0~1 Switches between LEF and SEF.,0: LEF,1: SEF
710-613 Fax Job Mixed-Sizes Standard Mode 0 0~1 Switches to a size (standard/non-standard) that DADF should report to IISS in Fax Mixed-Sizes
Mode.
0: Non-standard Mode
1: Standard Mode
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
711-001 DADF Lead Registration Adjustment (Side1)
(37.5mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-002 DADF Lead Registration Adjustment (Side1)
(50.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
