January 2007
6-227
WorkCentre 7132
Change Tag Introduction, IOT/Processor (P) Tags
General procedures information
Reversion 4.0
Change Tag Introduction
Important modifications to the copier are identified by a tag number which is recorded on a tag
matrix. The tag matrix for the IOT (Processor) is molded into the inside of the Front Door.
This section describes all of the tags associated with the copier, as well as multinational appli-
cability, classification codes, and permanent or temporary modification information.
Classification Codes
A tag number may be required to identify differences between parts that cannot be inter-
changed, or differences in diagnostic, repair, installation, or adjustment procedures.
A tag number may also be required to identify the presence of optional hardware, special non-
volatile memory programming, or whether mandatory modifications have been installed. Each
tag number is given a classification code to identify the type of change that the tag has made.
The classification codes and their descriptions are listed in the table below.
TAG: 1
CLASS: M
USE:
MFG SERIAL NUMBERS:
NAME: Front Auger
PURPOSE: To replace the defective Front Auger.
KIT NUMBER: 605K91980
PARTS LIST ON: PL 6.1
Table 1
Classification Code Description
M Mandatory tag
N Tag not installed in the field
O Optional tag
R Repair tag
