January 2007
2-714
WorkCentre 7132
092-662
Revision
Status-indicator-raps
092-662 Humidity Sensor RAP
BSD-ON:9.4A
There is a humidity sensor failure.
Procedure
Check the operating voltages between the Temperature/Humidity Sensor and the MCU PWB.
The voltages are correct.
YN
Verify that the circuit is not damaged. If no damage is found, replace the MCU PWB (PL
11.1).
Replace the Temperature/Humidity Sensor (PL 11.1).
