January 2007
6-170
WorkCentre 7132
Reversion 4.0
General procedures information
Analog Monitor
Table 1 Analog Monitor Code List
Chain-Link Nvm Name PSW Display Function Description
010-200 Heat Roll NC Sensor: Inf
NC Sensor Detection AD Value at the center of Heat Roll
010-201 Heat Roll NC Sensor: temp NC Sensor Compensation AD Value at the center of Heat Roll
010-202 Heat Roll NC Sensor: Diff NC Sensor Difference AD Value at the center of Heat Roll
(Compensation AD Value - Detection AD Value) x 14.333
010-202 Heat Roll STS
Temperature AD Value at Heat Roll Front
071-200 Tray1 Size Switch Tray2 Size Switch Displays Tray 1 Paper Size AD Value.
072-200 Tray2 Size Switch(2TM) Tray2 Size Switch Displays Tray 2 Paper Size AD Value.
072-201 Tray2 Size Switch(TTM) Tray2 Size Switch
Displays Tray 2 Paper Size AD Value.
073-200 Tray3 Size Switch(2TM) Tray3 Size Switch Displays Tray 3 Paper Size AD Value.
073-201 Tray3 Size Switch(TTM) Tray3 Size Switch Displays Tray 3 Paper Size AD Value.
092-200 ADC Sensor ADC Sensor Monitors reflective ratio on the belt of ADC_SNRS at regular intervals.
092-201 TEMP Sensor ENV TEMP Sensor Monitors temperature sensor at regular intervals.
092-202 HUM Sensor ENV HUM Sensor Monitors temperature sensor at regular intervals.
