Xerox WorkCentre 7132 Service Documentation

January 2007
2-589
WorkCentre 7132
041-341, 041-342
Status-indicator-raps
Revision
041-341 MCU PWB Access RAP
BSD-ON:3.1
There is a MCU PWB Access failure. Read check values do not match write check values.
Initial Actions
Ensure that the MCU PWB E-PROM is secure on the MCU PWB.
Procedure
Check the connection of each MCU PWB connector. The connectors are connected cor-
rectly.
YN
Secure the connectors.
Turn on the power again. [041-341] persists.
YN
Return to Service Call Procedures.
Initialize NVM. [041-341] persists.
YN
Return to Service Call Procedures.
Replace the MCU PWB (PL 11.1).
041-342 MCU PWB Buffer RAP
BSD-ON:3.1
There is a MCU PWB Buffer full or overflow problem.
Initial Actions
Ensure that the MCU PWB E-PROM is secure on the MCU PWB (PL 11.1).
Procedure
Check the connection of each MCU PWB connector. The connectors are connected cor-
rectly.
YN
Secure the connectors.
Turn on the power again. [041-342] persists.
YN
Return to Service Call Procedures.
Replace the MCU PWB (PL 11.1).
