January 2007
2-336
WorkCentre 7132
024-951, 024-952
Revision
Status-indicator-raps
024-951 TTM Tray 2 Empty RAP
BSD-ON:7.11
Tray 2 is out of paper.
Initial Actions
• Power Off/On
Procedure
Check the installation of the Tray 2 No Paper Sensor (PL 15.6) and the operation of the actua-
tor. The Tray 2 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 2 Level Sensor.
Execute Component Control [072-102 Tray 2 No Paper Sensor]. Manually activate the Tray 2
No Paper Sensor (PL 15.6).
The display changes.
YN
Check the connections of P/J102B, P/J661B and P/J549. Connectors are connected
correctly.
YN
Connect P/J102B, P/J661B and P/J549.
Check the wire between J102B and J549 for an open circuit or a short circuit (BSD 7.11
Flag 5/Flag 4).
The wire between J102B and J549 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P549-25 (+) and GND (-) (BSD 7.11
Flag 5).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 15.9).
Measure the voltage between the Tray Module PWB P549-27 (+) and GND (-) (BSD 7.11
Flag 4).
Activate the actuator of the Tray 2 No Paper Sensor (PL 15.6). The voltage changes.
YN
Replace the Tray 2 No Paper Sensor (PL 15.6).
Replace the Tray Module PWB (PL 15.9).
Replace the Tray Module PWB (PL 15.9).
024-952 2TM Tray 3 Empty RAP
BSD-ON:7.10
Tray 3 is out of paper.
Initial Actions
• Power Off/On
Procedure
Check the installation of the Tray 3 No Paper Sensor (PL 14.3) and the operation of the actua-
tor. The Tray 3 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 3 Level Sensor.
Execute Component Control [073-101 Tray 3 No Paper Sensor]. Manually activate the Tray 3
No Paper Sensor (PL 14.3).
The display changes.
YN
Check the connections of P/J102A, P/J661A and P/J549. Connectors are connected
correctly.
YN
Connect P/J102A, P/J661B and P/J549.
Check the wire between J102A and J549 for an open circuit or a short circuit (BSD 7.10
Flag 4/Flag 5).
The wire between J102A and J549 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P549-10 (+) and GND (-) (BSD 7.10
Flag 5).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 14.7).
Measure the voltage between the Tray Module PWB P549-12 (+) and GND (-) (BSD 7.10
Flag 4).
Activate the actuator of the Tray 3 No Paper Sensor (PL 14.3). The voltage changes.
YN
Replace the Tray 3 No Paper Sensor (PL 14.3).
Replace the Tray Module PWB (PL 14.7).
Replace the Tray Module PWB (PL 14.7).
To Next Page
