January 2007
6-172
WorkCentre 7132
Initialize HFSI Counters
Reversion 4.0
General procedures information
Initialize HFSI Counters
Purpose
Initialize the HFSI Counter.
Procedure
Reading and resetting HFSI
1. Enter UI Diagnostic Mode.
2. Select Adjustment/Other.
3. Select Initialize HFSI Counter.
4. Reset Correct Value
a. Enter the Chain-Link No.
b. Select Reset Correct Value. Diagnostics routine completed will be displayed
NOTE: Diagnostics routine completed will be displayed. The HFSI Counter is reset.
HFSI
Table 1 IOT HFSI
Chain-Link Name
Initial
Value
Value 1Count Remarks
954-807 Last 2Digits of Fuser discharging Number 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-807 5th&6thDigits of Fuser discharging Number 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-807 3rd&4thDigits of Fuser discharging Number 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-807 First 2Digits of Fuser discharging Number 0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-800 Tray1 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-800 Tray1 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-800 Tray1 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-800 Tray1 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-801 Tray2 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-801 Tray2 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-801 Tray2 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-801 Tray2 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-802 Tray3 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-802 Tray3 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-802 Tray3 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-802 Tray3 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-804 HCF Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
