Xerox WorkCentre 7132 Service Documentation

January 2007
6-173
WorkCentre 7132
Initialize HFSI Counters
General procedures information
Reversion 4.0
954-804 HCF 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-804 HCF 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-804 HCF First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-805 MSI Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-805 MSI 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-805 MSI 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-805 MSI First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-808 Last 2Digits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-808 5th&6thDigits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-808 3rd&4thDigits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~99 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
954-808 First 2Digits of the number of Sheets Reaching BIAS transfer
Roll(8 Digits)
0 0~3 1 Only 0 clearance is possible in the write mode.(’0 clearance’ means all bytes
changes 0 at the same time.)
Table 1 IOT HFSI
Chain-Link Name
Initial
Value Value 1Count Remarks
