January 2007
2-633
WorkCentre 7132
071-105
Status-indicator-raps
Revision
071-105 Registration Sensor RAP
BSD-ON: 8.7
A sheet did not actuate the Registration Sensor in time.
Procedure
Execute Component Control [089-100 Registration Sensor]. Manually activate the actuator of
the Registration Sensor (PL 2.5).
The display changes.
YN
Check the wires between P/J106 and P/J405 for an open circuit or a short circuit (BSD
8.7 Flag 1/Flag 2).
The circuit between P/J106 and P/J405 is conducting without an
open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P/J405-8A (+) and P/J405-6A (-) (BSD 8.7
Flag 2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 11.1).
Measure the voltage between the MCU PWB P/J405-A7 (+) and GND (-) (BSD 8.7 Flag
1). Actuate the Registration Sensor with paper.
The voltage changes.
YN
Replace the Registration Sensor (PL 2.5).
Replace the MCU PWB (PL 11.1).
Check the paper transport drives and repair as required (PL 1.1, PL 2.5).
