January 2007
2-142
WorkCentre 7132
012-282
Revision
Status-indicator-raps
012-282 Eject Clamp Home Sensor Off RAP
BSD-ON:12.7
After the Eject Clamp started descending, the Eject Clamp Home Sensor did not turn Off within
200ms.
Initial Actions
• Power Off/On
• Remove foreign substances in the Eject Clamp mechanism.
Procedure
Manually operate the Eject Clamp mechanism. The Eject Clamp mechanism moves
smoothly.
YN
Replace the parts that are interfering with operation.
Execute Component Control [012-250 Eject Clamp Home Sensor]. Actuate the Eject Clamp
Home Sensor with paper.
The display changes.
YN
Check the connections of P/J8803 and P/J8849. P/J8803 and P/J8849 are con-
nected correctly.
YN
Connect P/J8803 and P/J8849.
Check the wire between J8803 and J8849 for an open circuit or a short circuit (BSD 12.7
Flag 3/Flag 4).
The wire between J8803 and J8849 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8849-6 (+) and GND (-) (BSD 12.7 Flag
4).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 17.12).
Measure the voltage between the Finisher PWB P8849-5 (+) and GND (-) (BSD 12.7 Flag
3).
Actuate the Eject Clamp Home Sensor with paper. The voltage changes.
YN
Replace the Eject Clamp Home Sensor (PL 17.7).
Replace the Finisher PWB (PL 17.12).
Alternately execute Component Control [012-081 Eject Motor FORWARD ON] and Component
Control [012-082 Eject Motor REVERSE ON].
The Eject Motor starts up.
YN
Check the connections of P/J8801 and P/J8846. P/J8801 and P/J8846 are con-
nected correctly.
YN
Connect P/J8801 and P/J8846.
Check the wire between J8801 and J8846 for an open circuit or a short circuit (BSD 12.7
Flag 5).
The wire between J8801 and J8846 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Eject Motor between J8801-2/5 (COM) and each point of
J8801-1/3/4/6 (BSD 12.7).
The resistance is approx. 2Ohm.
YN
Replace the Eject Motor (PL 17.7).
Measure the voltage between the Finisher PWB P8846-6 (+) and GND (-), and between
P8846-12 (+) and GND (-) (BSD 12.7).
The voltage is approx. +24VDC.
YN
Replace the Finisher PWB (PL 17.12).
Replace the Eject Motor (PL 17.7). If the problem persists, replace the Finisher PWB (PL
17.12).
Replace the Finisher PWB (PL 17.12).
A
A
B
B
