Status-indicator-raps
124-335 Font ROM RAP
BSD-ON:16.1
The Font ROM could not be detected.
Initial Actions
Power Off/On
Procedure
Pull out and insert the Printer PWB (PL 11.1) and the DIMM (PL 11.2) Switch on the power.
The problem persists.
YN
Return to Service Call Procedures.
Check the connection of each ESS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the PS DIMM (PL 11.2).
If the problem persists replace the Printer PWB (PL 11.2).
f the problem persists replace the ESS PWB (PL 11.2)
124-337 ESS Standard RAM RAP
BSD-ON:16.1
An error was detected in the ESS Built-In Standard RAM.
Procedure
Reinstall or replace the DDR DIMM (PL 11.2).
If the problem persists replace the ESS PWB (PL 11.2).
