Xerox WorkCentre 7132 Service Documentation

January 2007
2-601
WorkCentre 7132
045-331, 045-332
Status-indicator-raps
Revision
045-331 Marking Reject RAP
BSD-ON:6.4/6.5
There is a marking reject control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
045-332 Marking Reject RAP
BSD-ON:6.4/6.5
There is a marking reject control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
