Xerox WorkCentre 7132 Service Documentation

January 2007
2-114
WorkCentre 7132
010-313, 010-314
Revision
Status-indicator-raps
010-313 Control (Center) Thermistor RAP
BSD-ON:10.2
The Control (Center) Thermistor has an open circuit.
Initial Actions
• Power Off/On
Procedure
Check the installation of the Fuser Unit. The Fuser Unit is securely installed.
YN
Install the Fuser Unit securely.
Check the resistance of the Center Thermistor between P615-5 and P615-9 (BSD 10.2 Flag
2).
The resistance is 3k ohms or higher.
YN
Replace the Fuser Unit (PL 7.1).
Check the wire between J422 and P615 for an open circuit or a short circuit (BSD 10.2 Flag 3/
Flag 2).
The wire between J422 and P615 conducts as expected.
YN
Repair the open circuit or short circuit.
Replace the Fuser Unit (PL 7.1). If the problem persists, replace the MCU PWB (PL 11.1).
010-314 Rear Thermistor RAP
BSD-ON:10.1
The Rear Thermistor has an open circuit.
Initial Actions
• Power Off/On
Procedure
Check the installation of the Fuser Unit. The Fuser Unit is securely installed.
YN
Install the Fuser Unit securely.
Check the resistance of the Rear Thermistor between P615-12 and P615-11 (BSD 10.2 Flag 3/
Flag 2).
The resistance is 3k ohms or higher.
YN
Replace the Fuser Unit (PL 7.1).
Check the wire between J422 and J615 for an open circuit or a short circuit (BSD 10.2 Flag 3/
Flag 2).
The wire between J410 and J615 conducts as expected.
YN
Repair the open circuit or short circuit.
Replace the Fuser Unit (PL 7.1). If the problem persists, replace the MCU PWB (PL 11.1).
