January 2007
2-634
WorkCentre 7132
071-211, 071-212
Revision
Status-indicator-raps
071-211 Tray 1 RAP
BSD-ON:7.1
The Tray 1 Paper Size Switch failed.
Initial Actions
Ensure the tray is set up and loaded correctly.
Procedure
Remove Tray 1. Check the condition of the Tray 1 Paper Size Switch and actuators. The Tray
1 Paper Size Switch and actuators appear to be free of damage.
YN
Replace the Tray 1 Paper Size Switch (PL 2.1).
Check the Tray 1 actuator on the back of Tray 1. The actuator is good.
YN
Repair as required (PL 2.1)
Go to the OF 2 Size Switch Assy RAP.
071-212 Tray 1 Ready RAP
BSD-ON:7.7
There is a Tray 1 ready failure.
Procedure
Switch the power off then on. If the problem continues disconnect and reconnect P/J424 on
the MCU PWB.
To Next Page
