January 2007
2-731
WorkCentre 7132
093-962, 093-970
Status-indicator-raps
Revision
093-962 Toner C CRUM Data Mismatch Failure
BSD-ON:9.1
C Toner CRUM Data Mismatch Failure.
Initial Actions
• Ensure a Cyan Toner Cartridge is installed in the Cyan position in the Rotary
• Ensure the correct toner cartridge for this product is installed
• Ensure that the Cyan Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-926 (K), 093-960 (Y), and 093-961 (M) are also present on the UI.
YN
Replace the Cyan Toner Cartridge (PL 5.2).
Replace the Toner CRUM (Toner Cartridge Door) (PL 5.1).
If the fault codes are still present, replace the MCU PWB (PL 11.1).
093-970 Toner Y CRUM not in position Failure
BSD-ON:9.1
Y Toner CRUM not in position Failure.
Initial Actions
• Ensure that the Yellow Toner Cartridge is seated correctly.
• Ensure that the Toner Cartridge Door is closed.
Procedure
Fault codes 093-916 (K), 093-971 (M), and 093-972 (C) are also present on the UI.
YN
Replace the Yellow Toner Cartridge (PL 5.2).
Replace the Toner CRUM (Toner Cartridge Door) (PL 5.1).
If the fault codes are still present, replace the MCU PWB (PL 11.1).
