Xerox WorkCentre 7132 Service Documentation

January 2007
4-171
WorkCentre 7132
REP 16.7.1, REP 16.8.1
Repairs/Adjustments
Reversion 4.0
NOTE: When installing the Actuator, ensure the stopper is inserted into the ditch of the
Actuator as illustrated below. (Figure 6)
Figure 6 Installing the Actuator
REP 16.8.1 Staple Unit Rail
Parts List on PL 17.8
Removal
WARNING
To avoid personal injury or shock, do not perform repair or adjustment with electrical
power applied to the machine.
CAUTION
Check that “Ready to Copy” is displayed on the Control Panel display.
1. Remove the following parts:
• Staple Assembly (REP 16.8.2)
• Front Cover Assembly (REP 16.1.2)
• Rear Cover (REP 16.4.1)
2. Disconnect the connectors. (Figure 1)
1. Disconnect the connectors (x5).
2. Release the Edge Saddles (x4) to remove the wire.
3. Remove the screw to remove the Earth Wire.

Xerox WorkCentre 7132 Specifications

General

Functions	Print, Copy, Scan, Fax
Printing Technology	Laser
Print Speed (Black)	32 ppm
Print Resolution	1200 x 1200 dpi
Max Resolution (BW)	1200 x 1200 dpi
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Copier Max Resolution	600 x 600 dpi
Connectivity	Ethernet, USB
Scanner Type	Flatbed
Fax Speed	33.6 Kbps
USB Connectivity	USB 2.0
Media Size	A4, Letter, Legal
Copy Speed (Black)	32 ppm
Display	Color Touch Screen
Network Connectivity	Ethernet
